SS1050
KUER
Product Advantage
I. Product Positioning: Professional-Grade Commercial Cleaning Solution
The KUER SS1050 is a push-type, battery-powered industrial sweeper from Anhui KUER Cleaning Equipment Co., Ltd., part of its Walk Behind floor sweeper series. Designed for large-scale commercial/industrial applications such as supermarkets, factories, warehouses, and logistics parks, it focuses on "efficient coverage + low-maintenance" to address the low efficiency and high costs of traditional manual cleaning, while also balancing environmental protection and user experience.
II. Core Performance: Data-Driven Cleaning Strength
1. Efficient Coverage, Cleaning Over 10,000 Square Meters Per Day Cleaning Efficiency: Covering up to 4,500 square meters (approximately 48,440 square feet) per hour, it can clean 36,000 square meters in an eight-hour operation, equivalent to the area of six standard football fields. Cleaning Range: An ultra-wide 1050mm cleaning path, equipped with a 435mm main brush and dual 300mm side brushes, thoroughly cleans corners and crevices. A minimum turning radius of 1000mm makes it suitable for narrow aisles.
2. Long-lasting battery life and lower maintenance costs
Power: A maintenance-free 12V/70Ah battery provides 3 hours of continuous operation, meeting the needs of all-day cleaning for small and medium-sized sites. A full charge in 6-8 hours makes it suitable for shift cleaning.
Energy Control: Utilizing an energy-saving motor system (200W main brush + 90W dual side brushes + 50W vacuum), this electric sweeper consumes 60% less energy than traditional fuel-powered sweepers, significantly reducing carbon emissions. 3. User-friendly design, extremely low operating threshold
Easy to operate: Weighing only 90kg, the push-type design requires no specialized driving skills, making it easy for female employees to operate. Its 20% gradeability makes it suitable for sites with slight slopes (such as warehouse unloading platforms).
Quiet operation: Low-noise motor technology produces less than 65dB of noise during operation, making it suitable for use in noise-sensitive environments such as supermarkets and offices without disrupting normal operations.
Technical Parameters
| Model | KUER-SS1050 |
| Cleaning Path / Brush Size | 1050mm |
| Cylindrical Brush Width / Side Brush Width | 435mm/300mm |
| Max.coverage Per Hour | 4500㎡/h |
| Continious Operating Time | 3h |
| Water Tank Capacity / Debris Tank Capacity | 30/35L |
| Battery (Free Maintenance) | 12V/80AH |
| Drive Motor | / |
| Vacuum Motor | 50W |
| Cylidrical Brush Motor | 200W |
| side Brush Motor | 90W*2 |
| Operating Wweight | 90KG |
| Operating Size | 1080*1050*1080mm |
Product Uses
Applicable Scenario: Suitable for cleaning across all industries
1. Industrial: Cleans metal debris and dust from factory floors, with dust-proof design to protect equipment and personnel.
2. Commercial: Operates quietly in crowded areas like supermarkets and exhibition centers, ensuring no disruption to customers.
3. Logistics: Cleans dust between pallets in warehouses and sorting centers, ideal for cleaning between forklift operations.
Product Operate Guide
I. Pre-Operation Preparation
1. Check the device status
Confirm the battery level
Check the cleaning components
Confirm a safe environment
2. Adjust basic settings
Push the device and secure the hopper
If dust suppression is required, open the water tank valve
Adjust the height of the push rod
Turn on the main power switch
Gently push the device to test the push resistance and ensure smooth movement.
II. Official Cleaning Operation
Start the cleaning function
Standardize the cleaning motion
Dealing with special situations
III. Post-Cleaning Finishing
Shut down and clean the device
Clean the main and side brushes
Charging and storage
IV. Precautions
Do not use the device in flammable or explosive environments (such as paint shops) to avoid the danger of motor sparks.
Children and non-operating personnel are prohibited from touching the device. Be aware of pedestrians during cleaning to avoid accidental damage to the brush head.
If unusual noises or motor overheating occur, immediately stop the device for inspection and contact after-sales service (do not disassemble core components yourself).
FAQ
Q: What are the battery type and runtime of this machine?
A: It uses a 12V/100Ah lead-acid battery and can operate continuously for about 3 hours.
Q: What are the cleaning efficiency and cleaning width?
A: The cleaning efficiency is 4,500 m²/h, and the cleaning width is 1,050 mm.
Q: What are the advantages of this machine?
A: It offers high efficiency with dual side brushes and a main brush. Easy to operate with clearly marked control panel buttons. Excellent dust suppression performance with standard water mist function to effectively reduce airborne dust during cleaning. Compact and lightweight-only 90 kg-yet equipped with a large-capacity waste bin and clean water tank.
Q: What is the warranty period for this product?
A: The main unit is covered by a one-year warranty.
Q: Is it easy to maintain?
A: Yes. Routine maintenance only requires periodic replacement of the air filter. Both side and main brushes are easy to replace.
