XJ200S Ride-on Industrial Commercial Tile&concrete Floor Cleaning Machine Automatic Floor Cleaning Machine

XJ200S Ride-on Industrial Commercial Tile&concrete Floor Cleaning Machine Automatic Floor Cleaning Machine

Name: XJ200S Ride-on Industrial Commercial Tile&concrete Floor Cleaning Machine Automatic Floor Cleaning Machine
Brand: KUER
Rating: 5.0 (84 reviews)

The KUER XJ200S is a heavy-duty ride-on floor scrubber designed specifically for medium-to-large commercial and industrial sites. Unlike traditional push-type models, it features flexible operation, efficient cleaning, and easy-to-use operation. Suitable for daily cleaning needs in sites ranging from 5,000 to 15,000 square meters, it can replace multiple manual cleaning crews. The KUER XJ200S commercial floor scrubber features an automotive-grade painted chassis and an aircraft-grade cast aluminum squeegee, making it more durable and efficient. The KUER SJ200S industrial floor scrubber, meanwhile, is CE and ISO certified, balancing cleaning efficiency with site adaptability. It is particularly suitable for larger spaces requiring increased efficiency.

Quantity:
Availability:





Inquire Add to Basket

Model:
XJ200S
Brand:
KUER

large floor scrubber clean machine

Product Advantage

Technical Parameters

Product Uses

Product Operate Guide

FAQ

Product Advantage

1. Powerful Cleaning System

Dual-Brush Design: The KUER XJ200S industrial floor scrubber utilizes dual 19-inch high-efficiency brushes for a wider cleaning width and high floor coverage, easily removing oil, dust, and stubborn stains.

Adjustable Water Flow System: Adjust the water flow based on the level of dirt, optimizing cleaning results and reducing resource waste.

Efficient Water Suction System: The 200S ride-on electric floor scrubber features an obstacle-free squeegee design to prevent damage from collisions and provide excellent suction, ensuring instant drier cleaning.

2. Powerful Power and Battery Life

The KUER XJ200S commercial floor scrubber utilizes a 36V/200AH high-performance, maintenance-free battery, enabling 5-6 hours of continuous operation, meeting the daily cleaning needs of large areas.

The low-energy drive system ensures powerful power while effectively extending battery life and reducing operating costs.

3. Intelligent Operation and Safety Design

Intelligent Control Panel: One-touch start and stop functions, real-time status monitoring, making it easy for even novice operators to quickly master the system.

Ergonomic Cockpit: Comfortable and spacious operating space with a wide field of view, reducing fatigue from extended operation.

Safety Protection System: Equipped with an emergency brake, low-speed cornering protection, and anti-skid tires, ensuring safe driving.

4. Rugged and Durable Structural Design

Automotive-grade electrophoretic chassis: Highly corrosion-resistant and oxidative-resistant, suitable for diverse environments.

High-strength casing material: Effectively impact-resistant and wear-resistant, extending the service life of the vehicle.Modular Maintenance Design: Easily replace parts, reducing ongoing maintenance costs.

Technical Parameters

Model	KUER-XJ200S
Cleaning path mm(brush size"inch)	510mm/19"*2
Squeegee width	1200mm
Max.coverage per hour	7150㎡/h
Continious operating time	5-6h
Solution tank capacity	200L(52.8gal)
Recovery tank capacity	220L(58gal)
Battery(free maintenance)	36V/200A
Drive motor	650W（0.87hp)
Vacuum motor	600W(0.8hp)
Brush motor	650W(0.87hp)*2
Operating weight(inc.battery)	525KG
Operating size	186012001560mm

Product Uses

1. Factories and Manufacturing Workshops

Suitable for cleaning oil, dust, and residual liquids from floors in production workshops, warehouses, and logistics areas, enhancing safety and cleanliness.

2. Shopping Malls and Supermarkets

Quickly clean and dry high-traffic areas, keeping floors bright and clean, and creating a comfortable shopping environment.

3. Parking Lots and Underground Garages

Efficiently handles large areas, with a powerful suction system that removes accumulated water, mud, and dust, preventing vehicles from slipping.

4. Airports, Hospitals, and Train Stations

The quiet, low-noise design is suitable for public spaces with strict environmental noise requirements, providing an efficient and non-intrusive cleaning experience.

Product Operate Guide

I. Pre-Operation Preparation

1. Equipment Inspection

Battery

Components

Functions

2. Adding Consumables

Clean Water Tank

Waste Water Tank

Site Cleaning

II. Startup and Operation

1. Startup Procedure

① Insert the key and start the machine

② Select the operating mode on the control panel

③ Release the parking brake

2. Operation Techniques

Path Planning

Effect Adjustment

Status Monitoring

III. Shutdown and Closing

1. Shutdown Procedure

① Release the accelerator pedal, press the brake pedal, shift the gear to "Neutral," and apply the parking brake.

② Turn off the brush disc and water suction functions in sequence, then remove the key.

③ Lift the brush disc and squeegee, and move the machine to a drainage point and water source for subsequent cleaning.

2. Equipment Cleaning

3. Draining and Adding Water

4. Component Maintenance

Clean the filter and allow it to dry. Check the rubber strips for wear. If worn, turn them over or replace them immediately.

Storage: Wipe the body and control panel with a damp cloth and store the device in a dry and ventilated area. If not in use for extended periods, fully charge the battery and recharge it monthly.

III. Daily Maintenance Tips

Daily: Check the battery terminals for looseness or leakage; the seals in the water and wastewater tanks for aging or leakage; and the brake pedal for proper travel to ensure responsive braking.

Regular Maintenance

Weekly: Clean the water tank filter, check the lubrication of the brush bearings, and add special lubricant. Calibrate the squeegee height to ensure a firm contact with the floor.

Monthly: Check the battery voltage and adjust the brush height to 2-3mm off the ground. Inspect and replace if severely worn.

Charging Instructions: Wait 30 minutes after operation before charging. Use the original charger and avoid covering the charger's heat dissipation vents during charging. Once fully charged ("Full Charge" appears on the display), disconnect the power cord immediately. Do not overcharge for more than 12 hours.

Q:Which kinds of batteries can we choose?

A:Our standard configuration is Lead-acid battery, it also can use lithium battery according to customer's request

Q:Can you send me the video to show how the floor cleaning machine work?

A:Certainly, we have made video of every machine and uploaded them by our chain address.If you need, we will send you operation video.

Q: Does your company accept custom-made?

A:Yes, we accept it, OEM and ODM supported.If you want to be our distributor or agent, let's talk more details.
